| Product Name |
HUAWEI IdeaHub S2 |
| Product model |
86": IHS2-86SA |
| Product dimensions(H x W x D) |
86": 1212.0 mm x 1953.0 mm x 91.8 mm |
| Net weight |
86": 62.0 kg |
| Gross weight (including the package) |
86": 73.5 kg |
| * |
The dimensions and weight may vary with configuration, manufacturing process, and measurement method. The product height includes the camera (57 mm). |
| Device |
1 |
| Stylus pens |
2 |
| Cable |
Power cable x 1 |
| Wall-mounted bracket |
Optional (65", 75", and 86") |
| Rolling stand |
Optional (65", 75", and 86") |
| IdeaShare Key |
Optional (Type-A/Type-C port) |
| OPS |
Optional |
| Resolution |
4K (3840 x 2160 pixels) |
| Backlight type |
D-LED |
| Screen Lamination |
Zero-gap bonding |
| Latency |
16 ms |
| Touch sensing distance |
? 1.5 mm |
| Intelligent writing recognition |
Supports recognition of Chinese, English, French, Japanese, Spanish, Russian, Portuguese, Italian and 11 types of graphics |
| Resolution |
4K |
| Camera sharpness |
1800 lines |
| Lens cap for privacy protection |
? |
| Horizontal FoV |
80° |
| TV distortion |
<2% |
| Speaker frequency domain |
100 Hz to 20 kHz |
| Number of speaker units |
4 |
| Speaker total power |
40 W |
| Sound pickup angle |
180° |
| Sound pickup distance |
12 m |
| Microphone frequency domain |
80 Hz to 20 kHz |
| Optimized sound pickup |
Sound location, echo cancellation, and automatic gain control |
| Native meeting apps |
Huawei Cloud Meeting and WeLink |
| Dual streams (audio/video + data sharing) |
1080p30fps+1080p30fps/4K8fps |
| BYOM |
? |
| Auto-Framing |
? |
| Intelligent tracking |
? |
| Acoustic baffle |
? |
| DNN-based dereverberation |
? |
| CPU |
8-core |
| RAM |
8 GB |
| Flash |
64 GB |
| OS |
HarmonyOS, Windows (OPS required) |
| Security |
Embedded encryption chip that supports H.235, STARTTLS, TLS, SRTP encryption, Chinese cryptographic algorithms, secure boot, and TEE |
| Language |
Simplified Chinese, English, French, Japanese, Arabic, Spanish, Russian, German, Portuguese, and Italian |
| Wi-Fi module |
Wi-Fi 6 |
| Wi-Fi frequency |
2.4 GHz + 5 GHz |
| NFC |
? |
| Video input |
HDMI cable x 1 |
| Video output |
HDMI cable x 1 |
| Audio input |
·3.5 mm (line-in) x 1 ·HD-AI x 1 |
| Audio output |
3.5 mm (line-out) x 1 |
| Other ports |
·USB Type-A 3.0 x 3 ·USB Type-C x 1 ·RJ45 (10/100/1000 Mbit/s LAN) x 1 |
