| Integrated fixed device |
Y |
| Dimensions without packaging (H x W x D) |
Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 260.0 mm (1.72 in. x 17.40 in. x 10.24 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 267.0 mm (1.72 in. x 17.40 in. x 10.51 in.) |
| Dimensions with packaging (H x W x D) |
90.0 mm x 555.0 mm x 400.0 mm (3.54 in. x 21.85 in. x 15.75 in.) |
| Chassis height |
1 |
| Installation type |
Rack mounting,Desk mounting,Wall mounting |
| Weight without packaging |
3.0 (6.61) |
| Weight with packaging |
3.7 (8.16) |
| Typical power consumption |
22.0 |
| Typical heat dissipation |
75.07 |
| Maximum power consumption |
Without PoE: 22.0 W Full PoE load: 160.0 W (PoE: 124 W) |
| Maximum heat dissipation |
Without PoE: 75.07 Full PoE load: 545.94 |
| Static power consumption |
12.0 |
| 100% power consumption |
22.0 |
| MTBF |
57.77 |
| MTTR |
2 |
| Availability |
>0.99999 |
| Noise at normal temperature (acoustic power) |
Noise-free (no fans), < 30 |
| Noise at high temperature (acoustic power) |
Noise-free (no fans), < 30 |
| Noise at normal temperature (acoustic pressure) |
Noise-free (no fans), < 20 |
| Number of card slots |
0 |
| Number of power slots |
0 |
| Number of fans modules |
0 |
| Maximum number of physical ports on the entire device |
18 |
| Maximum number of 100GE ports |
0 |
| Maximum number of 40GE ports |
0 |
| Maximum number of 25GE ports |
0 |
| Maximum number of 10GE ports |
0 |
| Maximum number of 5GE ports |
0 |
| Maximum number of 2.5GE ports |
0 |
| Maximum number of GE ports |
18 |
| Maximum number of FE ports |
18 |
| Dedicated stack port |
Not supported |
| Redundant power supply |
Not supported |
| Long-term operating temperature |
0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.) |
| Restriction on the operating temperature variation rate |
When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). |
| Storage temperature |
–40°C to +70°C (–40°F to +158°F) |
| Long-term operating relative humidity |
5% RH to 95% RH (non-condensing) |
| Long-term operating altitude |
0–5000 m (0–16404 ft.) |
| Storage altitude |
0-5000 m (0-16404 ft.) |
| Power supply mode |
AC built-in |
| Rated input voltage |
AC input: 100–240 V AC; 50/60 Hz |
| Input voltage range |
AC input: 90 V AC to 300 V AC; 47 Hz to 63 Hz |
| Maximum input current |
3 A |
| CPU |
- |
| Memory |
- |
| Flash memory |
- |
| Console port |
Not supported |
| Eth Management port |
Not supported |
| USB |
Not supported |
| Hardware real-time power detection |
Not supported |
| Dying gasp |
Not supported |
| RTC |
Not supported |
| RPS input |
Not supported |
| Complete device sleeping |
Not supported |
| Service port surge protection |
Common mode: ±4 kV |
| Power supply surge protection |
Differential mode: ±6 kV; common mode: ±6 kV |
| Ingress protection level (dustproof/waterproof) |
IP20 |
| Types of fans |
None |
| Heat dissipation mode |
Natural heat dissipation |
| Airflow direction |
- |
| PoE |
Supported |
| Maximum PoE power consumption |
124 |
| PoE+ power interfaces |
16 |
| PoE++ power interfaces |
- |
| Full load PoE power consumption 15.4W (802.3af) |
8 |
| Full load PoE power consumption 30W (802.3at) |
4 |
| Full load PoE++ power consumption 60W (802.3bt) |
- |
| Full load PoE++ power consumption 90W (802.3bt) |
- |
| Certification |
EMC certification Safety certification Manufacturing certification |
