| Mechanical |
| Dimensions |
442 x 325 x 44 mm
(17.4 x 12.8 x 1.7") |
| Weight |
Without Mount: 4.6 kg (10.14 lb)
With Mount: 4.7 kg (10.36 lb) |
| Enclosure Material |
SGCC Steel |
| Hardware |
| Total Non-Blocking Throughput |
380 Gbps |
| Switching Capacity |
760 Gbps |
| Forwarding Rate |
565.44 Mpps |
| Max. Power Consumption |
100W |
| Power Method |
(1) Universal AC input, 100-240VAC, 2A Max, 50/60 Hz
(1) USP-RPS DC input, 11.5VDC, 8.7A |
| Power Supply |
AC/DC, Internal, 100W |
| Network Interface |
(28) 1/10 Gbps SFP+ Ethernet
(4) 1/10/25 Gbps SFP28 Ethernet* |
| LCM Display |
(1) 1.3" Touchscreen
Bootup Animation: Bootup in Progress
Firmware Upgrade Icon: Firmware Upgrading
Steady White: Factory Defaults, Awaiting Adoption
Steady Blue: Device is Adopted |
| LEDs |
SFP28/SFP+: White, Link and Activity |
| Management Interface |
Ethernet In-Band |
| Modes |
SMB Layer 3 10/25 G Fiber Switch |
| ESD/EMP Protection |
Air: ± 16kV, Contact: ± 12kV |
| Operating Temperature |
-5 to 40° C (23 to 104° F) |
| Operating Humidity |
10 - 90% Noncondensing |
| Certifications |
CE, FCC, IC |
*The four SFP28 ports don't support mixed speed at 25Gbps mode.
Once one of the SFP28 ports is configured at 25Gbps mode, the others will be limited at 25Gbps too.
The SFP28 ports only support mixed speed when all ports are at 1Gbps or 10Gbps.
