| Kamera |
| Képérzékelő |
1/2.7” Progressive Scan CMOS |
| Aperture |
4 mm: F2.4 |
| 6 mm: F2.0 |
| Optika |
4 mm / 6 mm |
| Lens Mount |
M12 |
| Min. szükséges megvilágítás |
Color: 0.1 Lux@F2.0; 0 Lux with IR |
| Day/Night Mechanism |
IR Cut Filter |
| Digital Noise Reduction |
3D DNR |
| WDR |
DWDR |
| Weatherproof Rating |
IP67 |
| IR Working Distance |
30m |
| Látószög |
4 mm, horizontal FOV: 92°, vertical FOV: 48°, diagonal FOV: 114° |
| 6 mm, horizontal FOV: 54°, vertical FOV: 31°, diagonal FOV: 62° |
| Hálózat |
| Szabvány |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| API |
ONVIF |
| Simultaneous Live View |
4 Main Streams & 3 Sub-Streams, or 3 Main Streams & 5 Sub-Streams |
| Biztonság |
Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| Fizikai kezelőfelület |
| Hálózati csatlakozás |
1 RJ45 10/100M Self-Adaptive Ethernet Port |
| Alarm |
- |
| Gomb |
- |
| Video Output |
- |
| Általános |
| Operating Temperature |
-30–60 °C |
| Tömeg |
283.5g |
| Csomagolás tartalma |
VIGI Network Camera |
| Quick Start Guide |
| Waterproof Cable Attachments |
| Mounting Bracket |
| Mounting Accessories |
| Méret (Ma x Sz x Mé) |
164.9 × 87.4 × 83.4 mm |
| Material |
Plastic |
| General Features |
Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening |
| Power Requirements |
12V DC ± 5%, 5.5mm Coaxial Power Plug |
| PoE (802.3af/at, class 0) |
| Power Supply |
12V DC ± 5%, 5.5mm Coaxial Power Plug |
| PoE (802.3af/at, class 0) |
| Power Consumption |
12V DC: Max 3W |
| PoE: Max 4W |
| Certifications |
CE, FCC, RCM, BSMI, VCCI, IP67, RoHS |
| Videó/Kép |
| Videó tömörítés |
Main stream: H.265/H.264 |
| Sub-Stream: H.265/H.264 |
| Kép frissítés (frame) és felbontás |
Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
| Resolution: 2304x1296, 2048x1280, 1920x1080, 1280x720, 704x576, 640x480, 352x288, 320x240 |
| Videótovábbítás |
Main Stream |
| Sub-Stream |
| Képbeállítás |
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software |
| Image Enhancement |
BLC/3D DNR/Prevent Overexposure to Infrared Light |
| Video Bit Rate |
64 Kbps to 6 Mbps |
| SMART FEATURE-SET |
| Smart Event |
Area Intrusion Detection, Line-Crossing Detection |
| Basic Event |
Motion Detection, Camera Tampering Detection, Exception ( illegal login) |
| Linkage Method |
Trigger Notification: ONVIF, HTTPS |
| Region of Interest |
1 Region |
