| First supported version |
V600R022C10 |
| Integrated fixed device |
Y |
| Dimensions without packaging (H x W x D) [mm(in.)] |
Basic dimensions (excluding the parts protruding from the body): 35.0 mm x 210.0 mm x 130.0 mm (1.38 in. x 8.27 in. x 5.12 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 35.0 mm x 210.0 mm x 136.3 mm (1.38 in. x 8.27 in. x 5.37 in.) |
| Dimensions with packaging (H x W x D) [mm(in.)] |
90.0 mm x 285.0 mm x 180.0 mm (3.54 in. x 11.22 in. x 7.09 in.) |
| Chassis height [U] |
0.8 |
| Installation type |
Desk mounting,Wall mounting |
| Weight without packaging [kg(lb)] |
0.8 (1.76) |
| Weight with packaging [kg(lb)] |
1.0 (2.2) |
| Typical power consumption [W] |
5.99 |
| Typical heat dissipation [BTU/hour] |
27.3 |
| Maximum power consumption [W] |
6.11 |
| Maximum heat dissipation [BTU/hour] |
30.7 |
| Static power consumption [W] |
4.25 |
| 100% power consumption [W] |
6.05 |
| MTBF [year] |
77.35 |
| MTTR [hour] |
2 |
| Availability |
>0.99999 |
| Noise at normal temperature (acoustic power) [dB(A)] |
Noise-free (no fans), < 30 |
| Noise at high temperature (acoustic power) [dB(A)] |
Noise-free (no fans), < 30 |
| Noise at normal temperature (acoustic pressure) [dB(A)] |
Noise-free (no fans), < 20 |
| Number of card slots |
0 |
| Number of power slots |
0 |
| Number of fans modules |
0 |
| Maximum number of physical ports on the entire device |
5 |
| Maximum number of 100GE ports |
0 |
| Maximum number of 40GE ports |
0 |
| Maximum number of 25GE ports |
0 |
| Maximum number of 10GE ports |
0 |
| Maximum number of 5GE ports |
0 |
| Maximum number of 2.5GE ports |
0 |
| Maximum number of GE ports |
5 |
| Maximum number of FE ports |
5 |
| Dedicated stack port |
Not supported |
| Redundant power supply |
Not supported |
| Long-term operating temperature [°C(°F)] |
0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.) |
| Restriction on the operating temperature variation rate [°C(°F)] |
When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). |
| Storage temperature [°C(°F)] |
–40°C to +70°C (–40°F to +158°F) |
| Long-term operating relative humidity [RH] |
5% RH to 95% RH (non-condensing) |
| Long-term operating altitude [m(ft.)] |
0–5000 m (0–16404 ft.) |
| Storage altitude [m(ft.)] |
0-5000 m (0-16404 ft.) |
| Power supply mode |
Power adapter |
| Rated input voltage [V] |
AC input: 100–240 V AC; 50/60 Hz |
| Input voltage range [V] |
AC input: 90 V AC to 264 V AC; 45 Hz to 65 Hz Power adapter output: 12 V DC |
| Maximum input current [A] |
1 A |
| CPU |
Quad-core, 800 MHz |
| Memory |
DDR4: 512 MB |
| Flash memory |
NAND Flash: 512 MB |
| Storage |
- |
| Console port |
Not supported |
| Eth Management port |
LAN port |
| USB |
Not supported |
| Hardware real-time power detection |
Not supported |
| Dying gasp |
Not supported |
| RTC |
Not supported |
| RPS input |
Not supported |
| Complete device sleeping |
Not supported |
| Service port surge protection [kV] |
Common mode: ±4 kV |
| Power supply surge protection [kV] |
Power adapter: ±6 kV in differential mode and ±6 kV in common mode |
| Ingress protection level (dustproof/waterproof) |
IP20 |
| Types of fans |
None |
| Heat dissipation mode |
Natural heat dissipation |
| Airflow direction |
- |
| PoE |
Not supported |
| Maximum PoE power consumption [W] |
- |
| PoE+ power interfaces |
- |
| PoE++ power interfaces |
- |
| Full load PoE power consumption 15.4W (802.3af) |
- |
| Full load PoE power consumption 30W (802.3at) |
- |
| Full load PoE++ power consumption 60W (802.3bt) |
- |
| Full load PoE++ power consumption 90W (802.3bt) |
- |
| Certification |
EMC certification Safety certification Manufacturing certification |
